Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
|
|
N A M E P L A T E D A T A
|
|
Manufacturer:
|
Western Gear
|
Our ID No.
|
002072
|
|
Model:
|
OD60
|
Ratio:
|
70.83:1
|
|
MO# or S/N
|
S/N 433
|
Alt. S/N
|
Order # 2808
|
|
IP Speed
|
280 RPM
|
HP rating
|
15 HP
|
Cat. Rating
|
|
| OP Speed:
|
3.95 RPM
|
SF / SC
|
|
|
Date
|
|
Oil Capacity
|
|
|
A D D I T I O N A L C A T A L O G I N F O R M A T I O N
|
|
Torque Rating
|
329,000 Lb-Inches
|
Shaft Diameters
|
High Speed:
3.125
Low Speed:
6.750
|
|
Weight
|
8,000 Lbs Approx.
|
Assembly
|
Assembly # 4
|
H.S. Shaft
RPM |
Ratio |
Approx. L.S.
Shaft RPM |
HP
Ratings |
|
1750 RPM
|
70.83:1
|
24.7 RPM
|
129 HP
|
|
1170 RPM
|
16.5 RPM
|
89.3 HP
|
|
870 RPM
|
12.3 RPM
|
69.5 HP
|
|
720 RPM
|
10.2 RPM
|
58.0 HP
|
|
580 RPM
|
8.2 RPM
|
47.7 HP
|
|
|
Notes:
|
Condition: Used
|
