Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
HOME
N A M E P L A T E       D A T A
Manufacturer:       FALK Our ID No.       007317
Model:       5EZ2A-06 Ratio:       7.812
MO# or S/N       7-184646-02 Alt. S/N
IP Speed       1750 HP rating       Cat. Rating
OP Speed:       224 SF / SC       2
Date       Oil Capacity
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating       13400 Lb-Inches Shaft Diameters High Speed:   1.875
Low Speed:   2.875
Weight       520 Lbs Approx. Assembly
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
7.812:1

230 RPM
48.6 HP
1430 RPM
190 RPM
40.8 HP
1170 RPM
155 RPM
34.2 HP
870 RPM
115 RPM
26.1 HP
720 RPM
95 RPM
21.8 HP
Notes:
Condition:


11/03 - REBUILT
