- Speed Reducer Data Sheet -
|
|
N A M E P L A T E D A T A
|
| Manufacturer: |
Falk |
Our ID No. |
005615 |
| Model: |
2135Y2B |
Ratio: |
45.56:1 |
| MO# or S/N |
7-866266-01 |
Alt. S/N |
|
| IP Speed | 1750 RPM |
HP rating |
108 BHP |
Cat. Rating |
|
| OP Speed: |
38.4 RPM |
SF / SC |
1.78 - SF |
| Date |
|
Oil Capacity |
37 | ||
| A D D I T I O N A L C A T A L O G I N F O R M A T I O N
|
| Torque Rating |
382,000 Lb-Inches |
Shaft Diameters |
High Speed: 3.250
Low Speed:
6.500 |
| Weight | 4630 Lbs Approx. |
Assembly |
Assembly #18 |
H.S. Shaft
RPM |
Ratio |
Approx. L.S.
Shaft RPM |
HP
Ratings |
| 1750
|
45.50:1 |
37
|
233 HP
|
| 1430
|
30
|
194 HP
|
| 1170
|
25
|
161 HP
|
| 870
|
18
|
122 HP
|
| 720
|
15
|
101 HP
|
| 580
|
12.5
|
82.2 HP
|
| Notes: |
Condition: NEW SURPLUS
Longer Than Standard Low Speed Shaft, N = 25-1/4" standard N is 23-1/2"
|
