- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      Falk Our ID No.      005722
Model:      425A2-A Ratio:      20.40:1
MO# or S/N      8-867070 Alt. S/N
IP Speed      1000 RPM HP rating      100 HP Cat. Rating
OP Speed:      49.02 RPM SF / SC      2.42 - SF
Date      2/89 Oil Capacity      16
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating      308,000 Lb-Inches Shaft Diameters High Speed:  3.000
Low Speed:  5.750
Weight      2700 Lbs Approx. Assembly      Parallel
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
20.40:1

84 RPM
419 HP
1430 RPM
68 RPM
344 HP
1170 RPM
56 RPM
283 HP
870 RPM
42 RPM
212 HP
720 RPM
34 RPM
175 HP
580 RPM
28 RPM
142 HP
Notes:
Condition:
