N A M E P L A T E       D A T A
Manufacturer:       FALK Our ID No.       007335
Model:       2100Y1 Ratio:       5.471
MO# or S/N       8-171483 Alt. S/N
IP Speed       1231 HP rating       300 Cat. Rating
OP Speed:       225 SF / SC       1.33
Date       11/87 Oil Capacity       7.2 GALS
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating       130000 Lb-Inches Shaft Diameters High Speed:   3.000
Low Speed:   5.000
Weight       1910 Lbs Approx. Assembly       2
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
5.471:1

350 RPM
713 HP
1430 RPM
280 RPM
604 HP
1170 RPM
230 RPM
511 HP
870 RPM
175 RPM
398 HP
720 RPM
140 RPM
339 HP
580 RPM
115 RPM
281 HP
Notes:
Condition: 3/03 - REBUILT
