N A M E P L A T E       D A T A
Manufacturer:       FALK Our ID No.       007446
Model:       2080Y1-LD Ratio:       2.760
MO# or S/N       8-765557 Alt. S/N
IP Speed       861 HP rating       200 Cat. Rating
OP Speed:       312 SF / SC
Date       4/87 Oil Capacity       6.0 GALS.
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating       72,000 Lb-Inches Shaft Diameters High Speed:   2.500
Low Speed:   4.000
Weight       1,000 Lbs Approx. Assembly
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
2.760:1

640 RPM
725 HP
1430 RPM
520 RPM
627 HP
1170 RPM
420 RPM
532 HP
870 RPM
320 RPM
416 HP
720 RPM
260 RPM
354 HP
580 RPM
210 RPM
294 HP
Notes:
Condition:
REBUILT: 1/05
