- Speed Reducer Data Sheet -
HOME
N A M E P L A T E       D A T A
Manufacturer:      FALK Our ID No.      008011
Model:      52-5EBZ4-16A2 Ratio:      60.14
MO# or S/N      6211-0458 Alt. S/N
IP Speed      1750 HP rating      5 Cat. Rating      SEE BELOW
OP Speed:      30 SF / SC      II 2
Date       Oil Capacity
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating      21,300 Lb-Inches Shaft Diameters High Speed:  1.000
Low Speed:  2.875
Weight      900 Lbs Approx. Assembly      Assembly 1
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
60.14:1

30 RPM
10 HP
1430 RPM
25 RPM
8.18 HP
1170 RPM
20 RPM
6.70 HP
870 RPM
15 RPM
4.98 HP
720 RPM
12.5 RPM
4.12 HP
Notes:
Condition:


Appears to be rebuilt
Low speed head can be rotated at 90 degrees to match your requirement
Ratio can be changed to match your existing unit
Can make into a 5CB3 or 5CB4
