- Speed Reducer Data Sheet -
HOME
N A M E P L A T E       D A T A
Manufacturer:      FALK Our ID No.      008027
Model:      2120Y1L
 		Ratio:      4.95
MO# or S/N      00-067346-01 Alt. S/N
IP Speed      1180 HP rating      450 Cat. Rating
OP Speed:      238 SF / SC      1.9
Date      8-00 Oil Capacity      26.5
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating      215,000 Lb-Inches Shaft Diameters High Speed:  4.000
Low Speed:  6.000
Weight       3,400 Lbs Approx. Assembly      19
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
4.95:1

350 RPM
1174 HP
1430 RPM
255 RPM
998 HP
1170 RPM
230 RPM
847 HP
870 RPM
175 RPM
663 HP
720 RPM
140 RPM
564 HP
580 RPM
115 RPM
470 HP
Notes:
Condition: Used
