Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      MORSE     PowerGear Our ID No.      008051
Model:      25RW
     25RW10LRBT 		Ratio:      10
S/N      E98 ML0002 Center Distance      2.50
IP Speed      1750 HP rating      3.18
OP Speed:       SF / SC      1.0 - SF
A D D I T I O N A L       C A T A L O G       I N F O R M A T I O N
Torque Rating      938 Lb-Inches Shaft Diameters High Speed:0.750
Low Speed:1.250
Weight      50 Lbs Approx. Assembly      L-R
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
10:1

175 RPM
3.18 HP
1170 RPM
115 RPM
2.36 HP
870 RPM
87 RPM
1.99 HP
Notes:
