- Speed Reducer Data Sheet -
|
|
N A M E P L A T E D A T A
|
|
Manufacturer:
|
FALK REXNORD
|
Our ID No.
|
008118
|
|
Model:
|
2100Y1LD
|
Ratio:
|
4.190
|
|
MO# or S/N
|
92-065961-01
|
Alt. S/N
|
|
|
IP Speed
|
885
|
HP rating
|
295
|
Cat. Rating
|
See Below
|
| OP Speed:
|
211.2
|
SF / SC
|
1.75
|
|
Date
|
9/92
|
Oil Capacity
|
8.3
|
|
A D D I T I O N A L C A T A L O G I N F O R M A T I O N
|
|
Torque Rating
|
139,000 Lb-Inches
|
Shaft Diameters
|
High Speed:
3.000
Low Speed:
5.000
|
|
Weight
|
2100 Lbs Approx.
|
Assembly
|
1
|
H.S. Shaft
RPM |
Ratio |
Approx. L.S.
Shaft RPM |
HP
Ratings |
Thermal
Ratings
W/O Cooling |
|
1750 RPM
|
4.190
|
420 RPM
|
919 HP
|
295 HP
|
|
1430 RPM
|
350 RPM
|
780 HP
|
343 HP
|
|
1170 RPM
|
280 RPM
|
661 HP
|
392 HP
|
|
870 RPM
|
210 RPM
|
516 HP
|
511 HP
|
|
720 RPM
|
175 RPM
|
440 HP
|
Exceeds Mechanical
|
|
580 RPM
|
140 RPM
|
365 HP
|
Exceeds Mechanical
|
|
|
Notes:
|
Condition: UNUSED SURPLUS or REBUILT with NEW GEARING
YOUTUBE
Operate gear drives only at horsepower, speed and ratio shown on nameplate. Before changing any one of these, submit complete nameplate data and new application conditions to the manufacturer for correct oil level, accessories, parts and application approval. Check unit for thermal capacity. Check unit for over hung load capacity if shaft connections are anything other the direct coupled.
|
