Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      Falk Our ID No.      000642
Model:      9GRB Ratio:      122.8:1
MO# or S/N      5260-0150 Alt. S/N
IP Speed      1150 RPM HP rating      15 HP Cat. Rating      21 HP
OP Speed:       SF / SC      1.4 - SF
Date       Oil Capacity
A D D I T I O N A L      C A T A L O G      I N F O R M A T I O N
Torque Rating      136,000 Lb-Inches Shaft Diameters High Speed:  1.5625
Low Speed:  4.6875
Weight      3000 Lbs Approx. Assembly
Notes:
