Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      Falk Our ID No.      001578
Model:      445A3AS Ratio:      55.92:1
MO# or S/N      8-765837 Alt. S/N
IP Speed      1750 RPM HP rating      150 HP Cat. Rating      254 HP
OP Speed:      31.3 RPM SF / SC      1.69 - SF
Date       Oil Capacity      29 Gals
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating      511,000 Lb-Inches Shaft Diameters High Speed:  2.250
Low Speed:  6.500
Weight       Assembly
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
55.92:1

-
-
1430 RPM
-
-
1170 RPM
20 RPM
172 HP
870 RPM
-
-
720 RPM
12.5 RPM
107 HP
580 RPM
-
-
Notes:
Condition: GOOD
Unit appears to have a size 1170T Coupling Hub on Low Speed Shaft
