Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      Horsburgh & Scott Our ID No.      002061
Model:      WT2000 Ratio:      10.25:1
MO# or S/N      M4760 Alt. S/N
IP Speed       HP rating      44.5 HP Cat. Rating
OP Speed:       SF / SC
Date       Oil Capacity
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating       Shaft Diameters High Speed:  2.000 *
Low Speed:  3.375 *
Weight      1,300 Lbs Approx. Assembly
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
10.25:1

170 RPM
46.3 HP
1430 RPM
-
-
1170 RPM
115 RPM
40.0 HP
870 RPM
85 RPM
35.3 HP
720 RPM
70 RPM
32.4 HP
580 RPM
55 RPM
28.9 HP
Notes:
* Shaft dimensions from the catalog. Actual dimensions have not been verified.
