- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      Falk Our ID No.      002079
Model:      2090GHB1A Ratio:      1.864:1
MO# or S/N      7-966705-01 Alt. S/N
IP Speed      1150 RPM HP rating      100 HP Cat. Rating      322 HP
OP Speed:      617 RPM SF / SC      3.22 - SF
Date       Oil Capacity      7.4 US GALS
A D D I T I O N A L      C A T A L O G      I N F O R M A T I O N
Torque Rating      32,700 Lb-Inches Shaft Diameters High Speed:  2.750
Low Speed:  3.000
Weight      1200 Lbs Approx. Assembly      Right Angle
Notes:

Condition:
