- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      FALK Our ID No.      005241
Model:      2100Y2S Ratio:      24.782:1
MO# or S/N      7-966545-01 Alt. S/N
IP Speed      1180 RPM HP rating      75 HP Cat. Rating      102 HP
OP Speed:      47.62 RPM SF / SC      1.36 - SF
Date       Oil Capacity      16
A D D I T I O N A L      C A T A L O G      I N F O R M A T I O N
Torque Rating      135,000 Lb-Inches Shaft Diameters High Speed:  2.500
Low Speed:  5.000
Weight      2100 Lbs Approx. Assembly
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750
24.782:1

70.6
177 HP
1430
57.7
149 HP
1170
47.2
125 HP
870
35
96.9 HP
720
29
82.0 HP
580
23.4
67.6 HP
Notes:

Condition: NEW SURPLUS
