- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      LINK BELT Our ID No.      005344
Model:      HWB100-35 Ratio:      384:1
MO# or S/N      W5-32756-C Alt. S/N
IP Speed      1750 RPM HP rating      3.8 HP Cat. Rating
OP Speed:       SF / SC      0.7 - SF
Date       Oil Capacity      17
A D D I T I O N A L      C A T A L O G      I N F O R M A T I O N
Torque Rating      39,100 Lb-Inches Shaft Diameters High Speed:  1.500
Low Speed:  3.375
Weight      39,100 Lbs Approx. Assembly      Right Angle Helical Worm
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750
384:1

4.5
3.3 HP
1430
3.7
2.9 HP
1170
3
2.5 HP
870
2.3
2.1 HP
580
1.5
1.5 HP
Notes:

Condition: USED SURPLUS
