Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      Falk Our ID No.      005506
Model:      5DTC3A Ratio:      79.56:1
MO# or S/N      04-030848-01 Alt. S/N
IP Speed       HP rating       Cat. Rating
OP Speed:       SF / SC
Date      1/04 Oil Capacity
A D D I T I O N A L      C A T A L O G      I N F O R M A T I O N
Torque Rating       Shaft Diameters High Speed:  1.7500
Low Speed:  3.9370
Weight      1,500 Lbs Approx. Assembly
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750
79.56:1

22
21 HP
1170
15
13.7 HP
Notes:

Condition: NEW SURPLUS
