Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
HOME
N A M E P L A T E       D A T A
Manufacturer:      Falk Our ID No.      006222
Model:      1110YF1-A Ratio:      4.926
MO# or S/N      8-065872-01 Alt. S/N
IP Speed      1150 HP rating      400 Cat. Rating
OP Speed:      233.5 SF / SC      1.75
Date      10-80 Oil Capacity      18
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating      186,000 Lb-Inches Shaft Diameters High Speed:  3.250
Low Speed:  5.500
Weight      2,700 Lbs Approx. Assembly      19
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
4.926

350 RPM
1049 HP
1430 RPM
280 RPM
874 HP
1170 RPM
230 RPM
728 HP
870 RPM
175 RPM
554 HP
720 RPM
140 RPM
465 HP
580 RPM
115 RPM
381 HP
Notes:
Condition: Used Surplus



Klistoff Equipment & Machinery, Inc.
PO Box 527
Woodburn, Oregon 97071


Tel: 1-503-982-0530
Fax: 1-503-981-3038

     Ask for:
John Klistoff
        or
Mark Ricci



Click on images for larger view.
