Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
HOME
N A M E P L A T E       D A T A
Manufacturer:       DODGE Our ID No.       007281
Model:       56CM21A Ratio:       192:1
MO# or S/N       M94419AM LF 079167-23-KB Alt. S/N
IP Speed       1750 HP rating       1.00 Cat. Rating
OP Speed:       9 SF / SC       1.00
Date       Oil Capacity
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating       4,814 Lb-Inches Shaft Diameters High Speed:   SPLINE SHAFT
Low Speed:   1.50
Weight       104 Lbs Approx. Assembly
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
192:1

9 RPM
1.03 HP
1170 RPM
6 RPM
0.84 HP
870 RPM
4.5 RPM
0.72 HP
Notes:
Condition: NEW

Klistoff Equipment & Machinery, Inc.
PO Box 527
Woodburn, Oregon 97071


Tel: 1-503-982-0530
Fax: 1-503-981-3038

     Ask for:
John Klistoff
        or
Mark Ricci
