Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      Falk Our ID No.      000605
Model:      140YB3A Ratio:      57.68:1
MO# or S/N      6-460905-01 Alt. S/N
IP Speed      1750 RPM HP rating      94 HP Cat. Rating
OP Speed:      30.3 RPM SF / SC      1.57 SF
Date       Oil Capacity
A D D I T I O N A L      C A T A L O G      I N F O R M A T I O N
Torque Rating      309,000 Lb-Inches Shaft Diameters High Speed:  2.250
Low Speed:  7.000
Weight      7,600 Lbs Approx. Assembly
Notes:
