Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      Falk Our ID No.      000610
Model:      2110Y2B Ratio:      39.97:1
MO# or S/N      7-264280-01 Alt. S/N
IP Speed      1750 RPM HP rating      75 HP Cat. Rating      128 HP
OP Speed:      43.8 RPM SF / SC      1.69 - SF
Date       Oil Capacity      21 US Gallons
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating      184,000 Lb-Inches Shaft Diameters High Speed:  2.750
Low Speed:  5.500
Weight      2800 Lbs Approx. Assembly
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
39.97:1

44 RPM
128 HP
1430 RPM
37 RPM
108 HP
1170 RPM
30 RPM
90 HP
870 RPM
22 RPM
68 HP
720 RPM
18 RPM
57 HP
580 RPM
-
-
Notes:
Condition:


Used, very good.
