Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      PHILADELPHIA Our ID No.      001646
Model:      1800DHA Ratio:      438:1
MO# or S/N      S/N 11973 Alt. S/N
IP Speed      1750 RPM HP rating      31 HP Cat. Rating      31 HP
OP Speed:      3.99 RPM SF / SC      1.0 - SF
Date       Oil Capacity
A D D I T I O N A L      C A T A L O G      I N F O R M A T I O N
Torque Rating      404,100 Lb-Inches Shaft Diameters High Speed:  2.3750
Low Speed:  6.3750
Weight      6000 Lbs Approx. Assembly
Notes:

Condition: GOOD





Klistoff Equipment & Machinery, Inc.
PO Box 527
Woodburn, Oregon 97071


Tel: 1-503-982-0530
Fax: 1-503-981-3038

     Ask for:
John Klistoff
        or
Mark Ricci



Click on images for larger view.
