Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      Falk Our ID No.      001663
Model:      1130YF1LS Ratio:      2.724:1
MO# or S/N      8-465534 Alt. S/N
IP Speed      817 RPM HP rating      700 HP Cat. Rating
OP Speed:      299.9 RPM SF / SC      2.16 - SF
Date       Oil Capacity      37 Gals
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating      329,000 Lb-Inches Shaft Diameters High Speed:  4.500
Low Speed:  6.500
Weight      5,500 Lbs Approximate Assembly      Parallel
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
2.724:1

642 RPM
3354 HP
1430 RPM
524 RPM
2805 HP
1170 RPM
429 RPM
2346 HP
870 RPM
319 RPM
1797 HP
720 RPM
-
-
580 RPM
-
-
Notes:
Condition: EXCELLENT
