Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      Farrel Our ID No.      002005
Model:      DR51-2 Ratio:      17.64:1
MO# or S/N      Order No. 64AD2949 Alt. S/N
IP Speed      870 RPM HP rating      600 HP Cat. Rating
OP Speed:       SF / SC
Date       Oil Capacity      70
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating      1,096,200 Lb-Inches Shaft Diameters High Speed:
Low Speed:
Weight      17,000 Lbs Approx. Assembly
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750
17.64:1

100 RPM
1503 HP
1430
-
-
1170
68 RPM
1087 HP
870
50 RPM
870 HP
720
-
-
580
-
-
Notes:
Condition: GOOD
