Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      Falk Our ID No.      002081
Model:      2120Y2A Ratio:      32.69:1
MO# or S/N      6-766316-01-1 Alt. S/N
IP Speed      1200 RPM HP rating      75 HP Cat. Rating      130 HP
OP Speed:      36.7 RPM SF / SC      1.73 - SF
Date       Oil Capacity      29 US Gals
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating      230,000 Lb-Inches Shaft Diameters High Speed:  3.000
Low Speed:  6.000
Weight      3,500 Lbs Approx. Assembly      Parallel
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
32.69:1

56 RPM
193 HP
1430 RPM
45 RPM
156 HP
1170 RPM
37 RPM
130 HP
870 RPM
28 RPM
99.2 HP
720 RPM
22 RPM
84.4 HP
580 RPM
18 RPM
69.4 HP
Notes:
Condition:
