Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      Falk Our ID No.      002121
Model:      302-1090FZ2A Ratio:      30.42:1
MO# or S/N      8-1M4895-01 Alt. S/N
IP Speed      1750 RPM HP rating      30 HP Cat. Rating
OP Speed:      56 RPM SF / SC      Class II
Date      11/81 Oil Capacity      14
A D D I T I O N A L      C A T A L O G      I N F O R M A T I O N
Torque Rating      90,800 Lb-Inches Shaft Diameters High Speed:  2.500
Low Speed:  4.000
Weight      1,100 Lbs Approx. Assembly
Notes:

Condition: Used Surplus
With Motor Bracket
