- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      DODGE TIGEAR      Our ID No.   005119
Model No:   Q-175-B-050-M-056-K1 Ratio:   50
S/N   MR94756 Center Distance   1.75
IP Speed   1750 HP rating   .43
OP Speed:   35 SF / SC  1.0 - SF
A D D I T I O N A L       C A T A L O G       I N F O R M A T I O N
Torque Rating   477 Lb-Inches Shaft Diameters High Speed:   56
Low Speed:   0.875
Weight   25 Lbs Approx. Assembly   K1
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
50:1

35 RPM
.43 HP
1170 RPM
23.4 RPM
.29 HP
Notes:
