- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      Morse Our ID No.      005232
Model:      100-Q-56-LR-10 Ratio:      10:1
MO# or S/N      XA0038D02N Alt. S/N
IP Speed      1750 RPM HP rating      .32 HP Cat. Rating
OP Speed:      175 RPM SF / SC      1.0 - SF
Date       Oil Capacity
A D D I T I O N A L      C A T A L O G      I N F O R M A T I O N
Torque Rating      102 Lb-Inches Shaft Diameters High Speed:  56C, Hollow
Low Speed:  .500, Solid
Weight      9.0 Lbs Approx. Assembly      Right Angle Worm, 56C, .500 Double Solid
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750
10:1

175
.32
1170
116
.27
Notes:

Condition: NEW SURPLUS
