- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      Dodge Our ID No.      005247
Model:      HF1082LN250TC Ratio:      24.94:1
MO# or S/N      5825583A-1 BD Alt. S/N
IP Speed      1750 RPM HP rating      30.55 HP Cat. Rating      30.55 HP
OP Speed:      70 RPM SF / SC      1.0 - SF
Date       Oil Capacity
A D D I T I O N A L      C A T A L O G      I N F O R M A T I O N
Torque Rating      27,438 Lb-Inches Shaft Diameters High Speed:  250TC, Solid
Low Speed:  2.375, Solid
Weight      350 Lbs Approx. Assembly      Inline Helical, 250TC, 2.375 Solid
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750
24.94:1

70
30.55 HP
1170
47
20.25 HP
Notes:

Condition: NEW SURPLUS
