Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      FALK Our ID No.      005338
Model:      52-1050FZB3AS Ratio:      38.34:1
MO# or S/N      8-239082 Alt. S/N
IP Speed      1750 RPM HP rating      5 HP Cat. Rating
OP Speed:      45 RPM SF / SC      Class II
Date      2/82 Oil Capacity
A D D I T I O N A L      C A T A L O G      I N F O R M A T I O N
Torque Rating      19,600 Lb-Inches Shaft Diameters High Speed:  1.625
Low Speed:  2.750
Weight      650 Lbs Approx. Assembly      Assembly #1 - Right Angle
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750
38.34:1

45
14.2 HP
1430
37
11.7 HP
1170
30
9.6 HP
870
22
7.19 HP
720
18
5.97 HP
580
15
4.83 HP
Notes:

Condition: NEW SURPLUS
Low Speed Right Angle
Head Can Be Rotated to Match Your Requirement
High Speed Gears Can Be Changed To Match Your Ratio
