- Speed Reducer Data Sheet -
HOME
N A M E P L A T E       D A T A
Manufacturer:       Our ID No.      005956
Model:      50Y1A Ratio:      1.921
MO# or S/N      6070-0042 Alt. S/N
IP Speed      850/1700 HP rating       Cat. Rating
OP Speed:      442.4/884 SF / SC
Date       Oil Capacity
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating      12,500 Lb-Inches Shaft Diameters High Speed:  1.750
Low Speed:  2.750
Weight      500 Lbs Approx. Assembly      ASSY 2
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
1.921

911 RPM
191 HP
1170 RPM
609 RPM
138 HP
870 RPM
453 RPM
108 HP
720 RPM
375 RPM
91.4 HP
580 RPM
302 RPM
76.0 HP
Notes:
Condition:
USED - GOOD TAKE OUT
