- Speed Reducer Data Sheet -
HOME
N A M E P L A T E       D A T A
Manufacturer:      HUB CITY Our ID No.      006383
Model:      5207
Ratio:      50
MO# or S/N      0220-71839 Alt. S/N
IP Speed       HP rating       Cat. Rating
OP Speed:       SF / SC
Date       Oil Capacity
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating       Lb-Inches Shaft Diameters High Speed:  0.875
Low Speed:  2.1875
Weight       Lbs Approx. Assembly      UR-L
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
50 :1

RPM
10.2 HP
1430 RPM
RPM
HP
1170 RPM
RPM
7.56 HP
870 RPM
RPM
5.86 HP
720 RPM
RPM
HP
580 RPM
RPM
HP
Notes:
Condition:
