Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
HOME
N A M E P L A T E       D A T A
Manufacturer:      FALK Our ID No.      006836
Model:      2160Y3S Ratio:      86.16
MO# or S/N      7-067751-01 Alt. S/N
IP Speed      1200 HP rating      75 Cat. Rating
OP Speed:      13.9 SF / SC      2.42
Date       Oil Capacity      102
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating      918,000 Lb-Inches Shaft Diameters High Speed:  2.750
Low Speed:  8.500
Weight      10,500 Lbs Approx. Assembly      24
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
86.16

20 RPM
296 HP
1430 RPM
16.5 RPM
245 HP
1170 RPM
13.5 RPM
203 HP
870 RPM
10.0 RPM
155 HP
720 RPM
8.3 RPM
130 HP
580 RPM
6.8 RPM
105 HP
Notes:
Condition:


Good take-out, longer then standard low speed shaft
