N A M E P L A T E       D A T A
Manufacturer:      Falk Our ID No.      006924
Model:      2120FZ3A Ratio:      47.71
MO# or S/N      00-030973 Alt. S/N
IP Speed      1750 HP rating      60 Cat. Rating      239
OP Speed:      36.7 SF / SC      3.98 SF
Date       Oil Capacity
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating      411,000 Lb-Inches Shaft Diameters High Speed:  2.250
Low Speed:  5.500
Weight      2,500 Lbs Approx. Assembly
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
47.71

37 RPM
239 HP
1430 RPM
30 RPM
197 HP
1170 RPM
25 RPM
162 HP
870 RPM
18 RPM
120 HP
720 RPM
15 RPM
99.7 HP
580 RPM
12.5 RPM
80.4 HP
Notes:
Condition:
Used, Good Condition
