- Speed Reducer Data Sheet -
HOME
N A M E P L A T E       D A T A
Manufacturer:       FALK Our ID No.       007272
Model:       1020FC2A Ratio:       25.21
MO# or S/N       90J9832 Alt. S/N
IP Speed       1750 HP rating       1.0 Cat. Rating
OP Speed:       28 SF / SC       2.33
Date       11/90 Oil Capacity       0.7
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating       2,110 Lb-Inches Shaft Diameters High Speed:   1.00
Low Speed:   1.50
Weight       Lbs Approx. Assembly
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
25.21:1

68 RPM
2.33 HP
1430 RPM
56 RPM
2.00 HP
1170 RPM
45 RPM
1.72 HP
870 RPM
34 RPM
1.32 HP
720 RPM
28 RPM
1.10 HP
580 RPM
22 RPM
0.886 HP
Notes:
Condition:   NEW SURPLUS
