- Speed Reducer Data Sheet -
HOME
N A M E P L A T E       D A T A
Manufacturer:       FALK Our ID No.       007285
Model:       1050FZB3A 001 Ratio:       38.34
MO# or S/N       920A0417-01 Alt. S/N
IP Speed       1750 HP rating       7.5 Cat. Rating
OP Speed:       45 SF / SC       1.0
Date       03-92 Oil Capacity       4.8 GALS
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating       11,400 Lb-Inches Shaft Diameters High Speed:   1.625
Low Speed:   2.750
Weight       340 Lbs Approx. Assembly
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
38.34:1

45 RPM
8.03 HP
1430 RPM
37 RPM
6.90 HP
1170 RPM
30 RPM
5.94 HP
870 RPM
22 RPM
4.76 HP
720 RPM
18 RPM
4.13 HP
580 RPM
15 RPM
3.48 HP
Notes:
Condition: NEW
