Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:       SUMITOMO PARAMAX Our ID No.       007315
Model:       PX8095P4 Y LR 180 Ratio:       187.200
MO# or S/N       VA0016265 Alt. S/N
IP Speed       1750 HP rating       137 Cat. Rating
OP Speed:       SF / SC
Date       1/00 Oil Capacity
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating       929,000 Lb-Inches Shaft Diameters High Speed:   1.875
Low Speed:   7.375
Weight       5,300 Lbs Approx. Assembly
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings		 Thermal
Ratings
W/O Cooling
1750 RPM
187.2:1

10 RPM
141 HP
199 HP
1170 RPM
7 RPM
94 HP
182 HP
870 RPM
5 RPM
71 HP
168 HP
Notes:
Condition: NEW SURPLUS
