Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
HOME
N A M E P L A T E       D A T A
Manufacturer:       FALK Our ID No.       007334
Model:       110FC2AB Ratio:       6.047
MO# or S/N       7-734559 Alt. S/N
IP Speed       1170 HP rating       200 Cat. Rating
OP Speed:       190 SF / SC
Date       9/77 Oil Capacity       22.0 GALS
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating       90300 Lb-Inches Shaft Diameters High Speed:   3.000
Low Speed:   4.750
Weight       1560 Lbs Approx. Assembly
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
6.047:1

280 RPM
415 HP
1430 RPM
230 RPM
354 HP
1170 RPM
190 RPM
297 HP
870 RPM
140 RPM
229 HP
720 RPM
115 RPM
189 HP
580 RPM
95 RPM
152 HP
Notes:
Condition:


REBUILT 10/98
