N A M E P L A T E       D A T A
Manufacturer:       FALK Our ID No.       007514
Model:       2140Y2-S Ratio:       11.53
MO# or S/N       8-764806 Alt. S/N
IP Speed       1170/143.8 HP rating       350 Cat. Rating
OP Speed:       101.5/12.5 SF / SC       1.85
Date       7/87 Oil Capacity       26 GALS
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating       444,000 Lb-Inches Shaft Diameters High Speed:   3.500
Low Speed:   7.250
Weight       7500 Lbs Approx. Assembly       19
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
11.53:1

155 RPM
1070 HP
1430 RPM
125 RPM
904 HP
1170 RPM
100 RPM
853 HP
870 RPM
77 RPM
590 HP
720 RPM
62 RPM
500 HP
580 RPM
50 RPM
413 HP
Notes:
Condition: USED
