- Speed Reducer Data Sheet -
HOME
N A M E P L A T E       D A T A
Manufacturer:       FALK Our ID No.       007612
Model:       2090Y3A Ratio:       69.92
MO# or S/N       6-660198-01 Alt. S/N
IP Speed       1760 HP rating       22 Cat. Rating       43.8
OP Speed:       25.2 SF / SC      1.99 SF
Date       Oil Capacity
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating       131,000 Lb-Inches Shaft Diameters High Speed:   1.500
Low Speed:   4.500
Weight       1,460 Lbs Approx. Assembly
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
69.92:1

25 RPM
43.8 HP
1170 RPM
16.5 RPM
29.9 HP
870 RPM
12.5 RPM
22.7 HP
720 RPM
10.0 RPM
18.9 HP
580 RPM
8.3 RPM
15.4 HP
Notes:
Condition: USED
