- Speed Reducer Data Sheet -
HOME
N A M E P L A T E       D A T A
Manufacturer:       Falk Our ID No.       007677
Model:       2155Y2B Ratio:       33.91
MO# or S/N       8-165522-01 Alt. S/N
IP Speed       1770 HP rating       350 Cat. Rating       465.50
OP Speed:       52.2 SF / SC       1.33
Date       Oil Capacity       72
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating       573,000 Lb-Inches Shaft Diameters High Speed:   3,500
Low Speed:   7,750
Weight       9,000 Lbs Approx. Assembly       18
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
33.91

50 RPM
465 HP
1430 RPM
40 RPM
390 HP
1170 RPM
34 RPM
330 HP
870 RPM
25 RPM
260 HP
720 RPM
21 RPM
220 HP
580 RPM
17 RPM
180 HP
Notes:
Condition:


Used
