- Speed Reducer Data Sheet -
HOME
N A M E P L A T E       D A T A
Manufacturer:      Falk Our ID No.      007788
Model:      2090Y1-A Ratio:      6.158
MO# or S/N      6-561480-01 Alt. S/N
IP Speed      1200 HP rating      125 Cat. Rating
OP Speed:      194.8 SF / SC      1.56
Date       Oil Capacity      5.25
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating      59,400 Lb-Inches Shaft Diameters High Speed:  2.75
Low Speed:  4.50
Weight      1630 Lbs Approx. Assembly      2
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
6.158

280 RPM
268 HP
1430 RPM
230 RPM
227 HP
1170 RPM
190 RPM
191 HP
870 RPM
140 RPM
148 HP
720 RPM
115 RPM
126 HP
580 RPM
95 RPM
104 HP
Notes:
Condition:
