Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      FALK Our ID No.      007824
Model:      2050GHB1-K Ratio:      4.071
MO# or S/N      93066066-01 Alt. S/N
IP Speed      1800 HP rating      30 Cat. Rating
OP Speed:      442.2 SF / SC      1.68
Date      6/93 Oil Capacity      .62
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating      7,400 Lb-Inches Shaft Diameters High Speed:  1.500
Low Speed:  1.750
Weight       Lbs Approx. Assembly      54
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings		 Thermal ratings
with 1 cooling fan
1750 RPM
4.071

420 RPM
50.5 HP
39 HP
1430 RPM
350 RPM
41.5 HP
Exceeds
Mechanical
Ratings
1170 RPM
280 RPM
34.2 HP
870 RPM
210 RPM
25.6 HP
720 RPM
175 RPM
21.2 HP
580 RPM
140 RPM
17.1 HP
Notes:
Condition:


Rebuilt Surplus
