Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      Falk Our ID No.      007830
Model:      1110FC2AC Ratio:      16.96
MO# or S/N      94-0A3887-01 Alt. S/N
IP Speed      1750 HP rating      200 Cat. Rating
OP Speed:      103 SF / SC      1.35
Date      8/94 Oil Capacity      22.00
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating      164,000 Lb-Inches Shaft Diameters High Speed:  3.00
Low Speed:  4.75
Weight      1560 Lbs Approx. Assembly
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings		 Thermal ratings
with 1 cooling fan
1750 RPM
16.96

100 RPM
269 HP
164 HP
1430 RPM
84 RPM
222 HP
166 HP
1170 RPM
68 RPM
184 HP
168 HP
870 RPM
50 RPM
138 HP
169 HP
720 RPM
42 RPM
115 HP
171 HP
580 RPM
34 RPM
93.4 HP
172 HP
Notes:
Condition:


Used Surplus
