- Speed Reducer Data Sheet -
HOME
N A M E P L A T E       D A T A
Manufacturer:      MORSE Our ID No.      007835
Model:      60DVX R-LD Ratio:      300.00
MO# or S/N      101MR0277 Alt. S/N
IP Speed      1750 HP rating      3.16 Cat. Rating
OP Speed:       SF / SC
Date       Oil Capacity
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating      22,453 Lb-Inches Shaft Diameters High Speed:  1.0000
Low Speed:  2.4375
Weight       Lbs Approx. Assembly
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
300.00

5.83 RPM
3.16 HP
1430 RPM
RPM
HP
1170 RPM
3.83 RPM
2.23 HP
870 RPM
2.90 RPM
1.77 HP
720 RPM
RPM
HP
580 RPM
1.93 RPM
1.25 HP
Notes:
Condition:


Unused Surplus
