N A M E P L A T E       D A T A
Manufacturer:      FALK Our ID No.      007844
Model:      301-6EBZ3-16B6 Ratio:      26.21
MO# or S/N      D7-433022-03 Alt. S/N
IP Speed       HP rating      30 Cat. Rating
OP Speed:       SF / SC      1
Date      6/74 Oil Capacity
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating      32,600 Lb-Inches Shaft Diameters High Speed:
Low Speed:  3.375
Weight      1090 Lbs Approx. Assembly
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
26.21

68 RPM
35.6 HP
1430 RPM
56 RPM
29.6 HP
1170 RPM
45 RPM
24.2 HP
870 RPM
34 RPM
18 HP
720 RPM
28 RPM
14.9 HP
580 RPM
28 RPM
HP
Notes:
Condition:


Unsused surplus, Some(little rust)Rust
