- Speed Reducer Data Sheet -
HOME
N A M E P L A T E       D A T A
Manufacturer:      FALK Our ID No.      007924
Model:      102-1060FZ3A Ratio:      38.73
MO# or S/N      8-5M3017-16 Alt. S/N
IP Speed      1750 HP rating      10 Cat. Rating
OP Speed:      45 SF / SC       2
Date      10/85 Oil Capacity      4.6
A D D I T I O N A L      C A T A L O G       I N F O R M A T I O N
Torque Rating      25,800 Lb-Inches Shaft Diameters High Speed:  1.625
Low Speed:  2.750
Weight      340 Lbs Approx. Assembly
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings
1750 RPM
38.73

45 RPM
18.5 HP
1430 RPM
37 RPM
15.4 HP
1170 RPM
30 RPM
12.7 HP
870 RPM
22 RPM
9.64 HP
720 RPM
18 RPM
8.06 HP
580 RPM
15 RPM
6.56 HP
Notes:
Condition:USED


Used Surplus
