Klistoff Equipment & Machinery, Inc.
- Speed Reducer Data Sheet -
N A M E P L A T E       D A T A
Manufacturer:      FALK Our ID No.      007990
Model:      2070Y1-L Ratio:      4.095:1
MO# or S/N      8-967290 Alt. S/N
IP Speed      1185 RPM HP rating      100 HP Cat. Rating
OP Speed:      289.4 SF / SC      2.46
Date      3/90 Oil Capacity      3
A D D I T I O N A L      C A T A L O G      I N F O R M A T I O N
Torque Rating      45,600 Lb-Inches Shaft Diameters High Speed:  1.750
Low Speed:  3.500
Weight      850 Lbs Approx. Assembly      18
H.S. Shaft
RPM		 Ratio Approx. L.S.
Shaft RPM		 HP
Ratings		 Thermal Rating
W/No Cooling
1750
4.471:1

950 RPM
689 HP
133
1430
780 RPM
591 HP
172
1170
640 RPM
484 HP
216
870
470 RPM
360 HP
285
720
390 RPM
298 HP
Thermal Exceeds Mechanical
580
320 RPM
240 HP
Thermal Exceeds Mechanical
Notes:

Condition: Used
