| Nameplate Data | |||||
|---|---|---|---|---|---|
| Manufacturer: | FALK | Our ID No. | 008559 | ||
| Model: | 602-1070FZ2A 1070FC2A | Ratio: | 6.155 | ||
| MO# or S/N | 82L1581-03 | Alt. S/N | |||
| IP Speed: | 1750 | HP rating: | 60 | Cat. Rating: | 173 |
| OP Speed: | 250 | SF / SC | II | ||
| Date: | 4/82 | Oil Capacity: | 5.0 | ||
| Additional Catalog Information | |||||
|---|---|---|---|---|---|
| Torque Rating | 38,300 Lb-Inches | High Speed Shaft Dia. | 2.125 | ||
| Weight | 500 Lbs Approx. | Low Speed Shaft Dia. | 3.250 | ||
| Shaft Height | 11.66 | C - Dimension | 28.34 Shaft end to Shaft end | ||
| H.S. Shaft RPM |
Ratio | Approx. L.S. Shaft RPM |
Mechanical HP Ratings |
Thermal ratings W cooling fan |
|---|---|---|---|---|
| 1750 RPM | 6.155:1 | 280 RPM | 173 HP | 90 HP |
| 1430 RPM | 230 RPM | 144 HP | 99 HP | |
| 1170 RPM | 190 RPM | 120 HP | 108 HP | |
| 870 RPM | 90.5 RPM | 140 HP | Exceeds Mechanical HP | |
| 720 RPM | 115 RPM | 75.5 HP | Exceeds Mechanical HP | |
| 580 RPM | 95 RPM | 61.4 HP | Exceeds Mechanical HP |
| Condition |
|---|
|
Notes: USED |
| Operate gear drives only at horsepower, speed and ratio shown on nameplate. Before changing any one of these, submit complete nameplate data and new application conditions to the manufacturer for correct oil level, accessories, parts and application approval. Check unit for thermal capacity. Check unit for over hung load capacity if shaft connections are anything other the direct coupled. |
