| Nameplate Data | |||||
|---|---|---|---|---|---|
| Manufacturer: | FALK | Our ID No. | 008655 | ||
| Model: | 1125YF1A | Ratio: | 6.120 | ||
| MO# or S/N | 7-466799-01-2 | Alt. S/N | |||
| IP Speed: | 1770 | HP rating: | 600 | Cat. Rating: | |
| OP Speed: | 289.2 | SF / SC | 1.60 | ||
| Date: | Oil Capacity: | 24.5 | |||
| Additional Catalog Information | |||||
|---|---|---|---|---|---|
| Torque Rating | 217,000 Lb-Inches | High Speed Shaft Dia. | 3.500 | ||
| Catalog Weight | 4,000 Lbs Approx. | Low Speed Shaft Dia. | 6.000 | ||
| Assembly | 18 | Centers | 18.000 | Shaft Height | 18.00 Inches |
| H.S. Shaft RPM |
Ratio | Approx. L.S. Shaft RPM |
Mechanical HP Ratings |
|---|---|---|---|
| 1750 RPM | 6.120:1 | 280 RPM | 982 HP |
| 1430 RPM | 230 RPM | 833 HP | |
| 1170 RPM | 190 RPM | 706 HP | |
| 870 RPM | 140 RPM | 550 HP | |
| 720 RPM | 115 RPM | 468 HP | |
| 580 RPM | 95 RPM | 388 HP |
| Condition |
|---|
|
Notes: USED |
| Operate gear drives only at horsepower, speed and ratio shown on nameplate. Before changing any one of these, submit complete nameplate data and new application conditions to the manufacturer for correct oil level, accessories, parts and application approval. Check unit for thermal capacity. Check unit for over hung load capacity if shaft connections are anything other the direct coupled. |
